PositionMaster EDP300 DIGITAL POSITIONER | OI/EDP300-EN REV. D 9
Type of protection Ex n - non-sparking
Basic device
Signal circuit (AI)
Terminals +11 / Æ12
Electrical values I
N
á 22 mA; U
max
á 30 V
Digital input (DI)
Terminals +81 / Æ82
Electrical values U
N
á 30 V
Digital output (DO)
Terminals +83 / Æ84
Electrical values U
N
á 30 V
Option modules
Module for the emergency shutdown function
Terminals +85 / Æ86
Electrical values U
N
á 30 V
Module for analog feedback (AO)
Terminals +31 / Æ32
Electrical values I
N
á 22 mA; U
N
á 30 V
Module for universal input (UAI)
Terminals +21 / Æ22
Electrical values I
N
á 22 mA; U
max
á 30 V
Module for digital feedback (SW1 / SW2)
Terminals SW 1: +41 / Æ42
SW 2: +51 / Æ52
Electrical values Per output: U
N
á 30 V
Limit switch (Limit 1 / Limit 2)
Limit monitor with proximity switches
Terminals Limit 1: +51 / Æ52
Limit 2: +41 / Æ42
Electrical values Per output: I
N
á 25 mA; U
N
á 16 V
* No IECEx approval
