PositionMaster EDP300 DIGITAL POSITIONER | OI/EDP300-EN REV. D 71
Menu: Device Info
Note
This menu is only used to display the device parameters. The parameters are displayed independently of the configured access level,
but cannot be changed.
Menu / parameter Value range Description
Device Info
Hardware Rev. The hardware revision is displayed here.
Software Rev. The firmware revision is displayed here.
Mounting Date The installation date is displayed here. The date can only be entered and changed using a PC (DTM /
EDD).
Commun. Tag The communication name is displayed here. The name can only be entered and changed using a PC (DTM
/ EDD).
Long Tag* The long text for the measuring point tag is displayed here.
Device Address The device address is displayed here.
Descriptor The measuring point tagging is displayed here. The description can only be entered and changed using a
PC (DTM / EDD).
Device Message The device information is displayed here. The description can only be entered and changed using a PC
(DTM / EDD).
Pneumatic Type Single / Safe
Single / Freeze
Double / Safe
Double / Freeze
The type of pneumatics that the device works with is displayed here.
After installing a different type of pneumatics, this type needs to be set in the ‘Service -> Pneumatic‘
menu.
• Single / Safe – Single acting, safety position with no current, with venting function
• Single / Freeze – Single acting, safety position with no current, with blocking function.
• Double / Safe – Double acting, safety position with no current, with venting function.
• Double / Freeze – Double acting, safety position with no current, with blocking function.
Stroke Time Up 0 to 200 s The stroke time determined by Auto Adjust (only Auto Adjust types ‘Stroke’ and ‘Full’) for the direction of
the 100 % position is displayed here.
Stroke Time Dn 0 to 200 s The stroke time determined by Auto Adjust (only Auto Adjust types ‘Stroke’ and ‘Full’) for the direction of
the 0 % position is displayed here.
* Visible only with HART® 7
