ABB PowerScale CABINET A User Manual

Section-4
04-3004_S4_OPM_ABB_POWERSCALE_10-50kVA_EN_150113.doc Page 5/8 ABB
Printed in Switzerland – Modifications reserved
4.1.3.3 Event Log Screen
4.1.3.4 Measurements Screen
DESCRIPTION
LCD-DISPLAY
1
Battery Runtime
BATT. RUN TIME (MIN)
00h 00m
2
UPS-Output Frequency
OUTPUT FREQUENCY (HZ)
50.00
3
Bypass Frequency.
BYPASS FREQUENCY (HZ)
50.00
4
Battery Voltage
BATTERY VOLTAGE (V)
+ 0.0 - 0.0
5
Battery Charger Current
BATT. CHARGE CUR. (A)
+ 0.0 - 0.0
6
Discharge Current.
DISCHARGE CURRENT (A)
00.00
7
Rectifier Voltage of all three phases
RECTIFIER VOLTAGE (V)
230 230 230
8
Bypass Voltage of all three phases
BYPASS VOLTAGE (V)
230 230 230
9
Output Voltage of all three phases
OUTPUT VOLTAGE (V)
230 230 230
10
Output Current of all three phases
OUTPUT CURRENT (A)
00.00 00.00 00.00
11
Active Output Power of all three phases
ACTIVE POWER (KW)
00.00 00.00 00.00
12
Reactive Output Power of all three phases
REACTIVE POWER (kVAr)
00.00 00.00 00.00
13
Apparent Output Power of all three phases
APPARENT POWER (KVA)
00.00 00.00 00.00
14
Output Power of all three phases
OUTPUT POWER (%)
00.00 00.00 00.00
15
Battery capacity
BATT. CAPACITY (%)
00.00
4.1.3.5 Commands Screen
DESCRIPTION
LCD-DISPLAY
1
Transfer Load to inverter
 LOAD TO INVERTER
LOAD TO BYPASS
2
Transfer Load to bypass.
 LOAD TO BYPASS
PERFORM BATT.TEST
3
Battery Test
 PERFORM BATT.TEST
NO MORE COMMANDS
DESCRIPTION
LCD-DISPLAY
1
Logging Control; a log of the last 99 events is
stored in the Power Management Display.
01 05-10-00
LOAD TO INV.
14-38-59
2
Every stored event is identified with a sequential
number and time stamp.
02 05-10-00
LOAD TO BYP.
14-38-56
3
All events and alarms are indicated with their date
and time of appearance.
03 05-10-00
LOAD OFF
14-37-14
