6.1.3 COMMISSIONING OF PARALLEL CONFIGURATION
THE OPERATIONS DESCRIBED IN THIS CHAPTER MUST BE PERFORMED BY A
SERVICE ENGINEER FROM THE MANUFACTURER OR FROM A AGENT
CERTIFIED BY THE MANUFACTURER.
6.1.3.1 Start-up of a Parallel Configuration
Before starting up a parallel Configuration verify that:
1. All the input and output cabling has been performed correctly according to section 2 of this User
Manual;
2. The parallel communication cables have been connected correctly according to Paragraph 6.1.2.2.1
3. All the DIP Switches for POWERSCALE - Cabinets been set correctly according to
Paragraphs 6.1.2.2.2 and 6.1.2.4
4. All the internal (if any) and /or external battery cabinets/racks have been connected correctly
The start-up of a parallel Configuration may be performed in analogy to the start-up procedures for a single
PowerScale - Cabinet described in Paragraph 1.1 of section 5.
6.1.3.2 Shutdown of Parallel Configuration
Before shutting-down of a Parallel Configuration make sure that the loads do need power protection and that they
are disconnected.
The UPS may be shut down completely if the loads do not need any power supply. Therefore the
steps in this Paragraph are to be performed only after the load has been disconnected.
To perform a complete shutdown of a Parallel Configuration proceed in analogy to the shutdown procedures
described in Paragraph 1.2 of section 5.
