ABB RED670 User Manual

3.4 Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v15
IEC 61850 or function
name
ANSI Function description Line Differential
RED670
(Customized)
RED670 (B33) RED670 (A42) RED670 (B42)
RED670 (C42)
Station communication
LONSPA, SPA SPA communication
protocol
1 1 1 1 1
ADE LON communication
protocol
1 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1 1
RS485GEN RS485 1 1 1 1 1
DNPGEN DNP3.0 communication
general protocol
1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485
communication protocol
1 1 1 1 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and
EIA-485 communication
protocol
1 1 1 1 1
MSTSER DNP3.0 serial master 1 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1
DNPFREC DNP3.0 fault records for
TCP/IP and EIA-485
communication protocol
1 1 1 1 1
IEC 61850-8-1 IEC 61850 1 1 1 1 1
GOOSEINTLKRCV Horizontal communication
via GOOSE for interlocking
59 59 59 59 59
GOOSEBINRCV GOOSE binary receive 16 16 16 16 16
GOOSEDPRCV GOOSE function block to
receive a double point
value
64 64 64 64 64
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand value
60 60 60 60 60
GOOSESPRCV GOOSE function block to
receive a single point value
64 64 64 64 64
MULTICMDRCV,
MULTICMDSND
Multiple command and
transmit
60/10 60/10 60/10 60/10 60/10
Table continues on next page
Section 3 1MRK 505 378-UEN A
Available functions
42 Line differential protection RED670 2.2 IEC
Commissioning manual

ABB RED670 Specifications

General

Rated Frequency	50/60 Hz
Product Type	Protection Relay
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, IEC 60870-5-103, DNP3
Operating Temperature Range	-25°C to +55°C
Protection Functions	Differential protection, distance protection, overcurrent protection
Outputs	Binary outputs
Enclosure	IP54
Mounting	19" rack mounting
