Setting parameters need to be calculated according to the electrical network
conditions and the electrical characteristics of the protected equipment. The IED's
settings need to be verified before the IED is connected to a system.
Document all changes to parameter settings.
For more information, see PCM600 documentation.
8.5.3.3 Defining disturbance recorder channel settings
1. Select Main Menu/Configuration/Disturbance recorder/Channel settings.
2.
Press or to scroll the view.
3.
To change channel settings, press .
Each analog channel has an equal set of parameters and correspondingly, each binary
channel has an equal set of parameters.
8.5.3.4 Configuring analog inputs
1.
Select Main Menu/Configuration/Analog inputs and press
.
2.
Select the analog input to be configured with or .
3.
Press , change the value with or and press again.
• For CTs, the secondary current and primary current need to be set to the
correct values.
• For VTs, the secondary voltage and primary voltage need to be set to the
correct values.
8.6 Testing IED operation
The IED has to be in the test mode before the digital outputs and certain output signals
of protection and other functions can be activated.
8.6.1 Selecting test mode
The test mode can be activated using the LHMI. The green Ready LED will be
flashing to indicate that the test mode is activated.
1MRS756708 A Section 8
Commissioning
615 series 109
Operation Manual
