• LHMI messages are shown in Courier font, for example:
To save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics, for example:
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks, for example:
The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier font,
for example:
When the function starts, the START output is set to TRUE.
1.4.3 Functions, codes and symbols
All available functions are listed in the table. All of these may not be applicable to
all products.
Table 1: Functions included in standard configurations
Function IEC 61850 IEC 60617 IEC-ANSI
Three-phase non-directional
overcurrent protection
PHLPTOC1 3I> 51P-1
PHHPTOC1 3I>> (1) 51P-2 (1)
PHHPTOC2 3I>> (2) 51P-2 (2)
PHIPTOC1 3I>>> 50P/51P
Three-phase directional overcurrent,
low stage
DPHLPDOC1 3I> → (1) 67-1 (1)
DPHLPDOC2 3I> → (2) 67-1 (2)
Three-phase directional overcurrent,
high stage
DPHHPDOC1 3I>> → 67-2
Arc protection ARCSARC1 ARC (1) 50L/50NL (1)
ARCSARC2 ARC (2) 50L/50NL (2)
ARCSARC3 ARC (3) 50L/50NL (3)
Non-directional earth-fault protection EFLPTOC1 I
0
> (1) 51N-1 (1)
EFLPTOC2 I
0
> (2) 51N-1 (2)
EFHPTOC1 I
0
>> 51N-2
EFIPTOC1 I
0
>>> 50N/51N
Directional earth-fault protection DEFLPDEF1 I
0
> → (1) 67N-1 (1)
DEFLPDEF2 I
0
> → (2) 67N-1 (2)
DEFHPDEF1 I
0
>> → 67N-2
Transient/Intermittent earth-fault
protection
INTRPTEF1 I
0
> → IEF 67NIEF
Non-directional (cross-country) earth
fault, using calculated I
0
EFHPTOC1 I
0
>> 51N-2
Negative-sequence overcurrent
protection
NSPTOC1 I
2
> (1) 46 (1)
NSPTOC2 I
2
> (2) 46 (2)
Phase discontinuity PDNSPTOC1 I
2
/I1> 46PD
Table continues on next page
1MRS756708 A Section 1
Introduction
615 series 11
Operation Manual
