When a computer is connected to the IED, the IED's DHCP server for the front
interface assigns an IP address to the computer. The fixed IP address for the front
port is 192.168.0.254.
3.3 WHMI
The WHMI enables the user to access the IED via a web browser. The supported web
browser version is Internet Explorer 7.0 or later.
WHMI is disabled by default. To enable the WHMI, select Main
Menu/Configuration/HMI/Web HMI mode via the LHMI. Reboot
the IED for the change to take effect.
WHMI offers the following functions:
• Alarm indications and event lists
• System supervision
• Parameter settings
• Measurement display
• Disturbance records
• Phasor diagram
The menu tree structure on the WHMI is almost identical to the one on the LHMI.
1MRS756708 A Section 3
615 series overview
615 series 23
Operation Manual
