Chapter 3 97
Replacing the Mainboard
1. Place the mainboard onto the upper cover.
2. Replace the one (1) screw to secure the mainboard to the upper cover.
Step Size Quantity Screw Type
Mainboard
Assembly
M2.5*4.0 1
