Acer Aspire 4738Z User Manual

82 Chapter 3
Removing the LCD Panel
1. See “Removing the LCD Bezel” on page 79.
2. Remove the six (6) securing screws from the LCD panel.
3. Remove the LVDS cable from the cable guides.
Step Size Quantity Screw Type
LCD Panel
Disassembly
M2.5*4.0 6

Acer Aspire 4738Z Specifications

General

RAM	2GB DDR3
Graphics	Intel HD Graphics
Weight	2.2 kg
Optical Drive	DVD-Super Multi DL drive
Wireless	802.11b/g/n
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	Multi-in-1 card reader
Display	14.0 inch HD LED LCD
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm (13.46 x 9.65 x 1.35 inches)
Processor	Intel Pentium P6200
