Acer Aspire 4738Z User Manual

102 Chapter 3
Replacing the LCD Module
1. Place the upper cover onto the LCD module and lower into place. Lower the hinges so they are flush with the
hinge plates on the upper cover.
2. Replace the four (4) screws to secure the left and right hinges.
Step Size Quantity Screw Type
LCD Module
Assembly
M2.5*6.5 4

Acer Aspire 4738Z Specifications

General

RAM	2GB DDR3
Graphics	Intel HD Graphics
Weight	2.2 kg
Optical Drive	DVD-Super Multi DL drive
Wireless	802.11b/g/n
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	Multi-in-1 card reader
Display	14.0 inch HD LED LCD
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm (13.46 x 9.65 x 1.35 inches)
Processor	Intel Pentium P6200
