Acer Aspire 4738Z User Manual

Chapter 3 99
Replacing the CPU
IMPORTANT:The CPU has a Pin1 locator (1) that must be positioned corresponding to the marker (2) on the
CPU socket.
1. Place the CPU into the CPU socket as shown, taking note of the Pin1 locator.
2. Using a slotted screw driver, rotate the CPU locking screw 180° clockwise as shown to secure it in the
package.
1
2

Acer Aspire 4738Z Specifications

General

RAM	2GB DDR3
Graphics	Intel HD Graphics
Weight	2.2 kg
Optical Drive	DVD-Super Multi DL drive
Wireless	802.11b/g/n
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	Multi-in-1 card reader
Display	14.0 inch HD LED LCD
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm (13.46 x 9.65 x 1.35 inches)
Processor	Intel Pentium P6200
