Acer Aspire 4738Z User Manual

112 Chapter 3
External Module Assembly Process
Replacing the ODD Module
1. Place the ODD bracket onto the ODD module and replace the two (2) screws to secure it.
2. Press the bezel into the tray, bottom edge first, to secure it to the ODD module.
Step Size Quantity Screw Type
ODD Bracket
Assembly
M2.0*3.0 2

Acer Aspire 4738Z Specifications

General

RAM	2GB DDR3
Graphics	Intel HD Graphics
Weight	2.2 kg
Optical Drive	DVD-Super Multi DL drive
Wireless	802.11b/g/n
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	Multi-in-1 card reader
Display	14.0 inch HD LED LCD
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm (13.46 x 9.65 x 1.35 inches)
Processor	Intel Pentium P6200
