Acer Aspire 4738Z User Manual

Chapter 3 107
Replacing the USB Board
1. Place the USB board onto the chassis.
2. Replace one (1) screw to secure the USB board.
3. Connect and lock the USB FFC to the USB board. Repeat for the mainboard connector.
Step Size Quantity Screw Type
USB Board
Assembly
M2.5*4.0 1

Acer Aspire 4738Z Specifications

General

RAM	2GB DDR3
Graphics	Intel HD Graphics
Weight	2.2 kg
Optical Drive	DVD-Super Multi DL drive
Wireless	802.11b/g/n
LAN	Gigabit Ethernet
Webcam	Acer Crystal Eye webcam
Card Reader	Multi-in-1 card reader
Display	14.0 inch HD LED LCD
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA
Dimensions	342 x 245 x 34.2 mm (13.46 x 9.65 x 1.35 inches)
Processor	Intel Pentium P6200
