Chapter 3 49

Disassembly Process

The disassembly process is divided into the following stages:

• External module disassembly

• Main unit disassembly

• LCD module disassembly

The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.

Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you

want to remove the mainboard, you must first remove the keyboard, then disassemble the inside assembly

frame in that order.

Main Screw List

Screw Quantity Part Number

M2.5*6.5 22 86.ARE07.001

M2.0*3.0 15 86.ARE07.002

M3.0*3.5 4 86.N1407.007

M2.5*4 9 86.EDM07.003

M2-0.4*2 1 86.W4107.002

M2.0*5 2 86.T23V7.010
