VOLTage Subsystem Introduction
VOLTage Subsystem Introduction
The VOLTage subsystem sets parameters related to output voltage.
Example
The following is a typical procedure using the VOLTage subsystem.
1. Select the waveform shape, amplitude and offset: Use APPLy or the equivalent FUNCtion, FREQuency,
VOLTage, and VOLTage:OFFSet commands to select the function, frequency, amplitude, and offset.
2. Set units for output amplitude:VOLTage:UNIT
3. Set output amplitude:VOLTage
4. Set DC offset voltage:VOLTage:OFFSet
5. Set high and low voltage level:VOLTage:HIGH and VOLTage:LOW
6. Select output voltage limits to protect device under test (DUT):VOLTage:LIMit:HIGH, VOLT-
age:LIMit:LOW, and VOLTage:LIMit:STATe
7. Select status of auto-ranging for all output functions:VOLTage:RANGe:AUTO
8. Set voltage coupling to lock amplitude and offset of the channels together:VOLTageLCOUPle[:STATe]
This code demonstrates the procedure outlined above:
SOURce1:FUNCtion SQU
SOURce1:FREQuency +1.0E+06
SOURce1:VOLTage +0.5
SOURce1:VOLTage:OFFSet +0.5
SOURce1:FUNCtion:SQUare:PERiod +1.0E-06
SOURce1:FUNCtion:PULSe:PERiod +1.0E-06
SOURce1:VOLTage:LIMit:LOW +0.0
SOURce1:VOLTage:LIMit:HIGH +1.0
SOURce1:VOLTage:LIMit:STATe 1
OUTP1 ON
SOURce2:FUNCtion SIN
SOURce2:FREQuency +1.0E+06
SOURce2:VOLTage +2.0
SOURce2:VOLTage:OFFSet +0.0
SOURce2:VOLTage:LIMit:LOW -1.0
SOURce2:VOLTage:LIMit:HIGH +1.0
SOURce2:VOLTage:LIMit:STATe 1
OUTP2 ON
[SOURce[1|2]:]VOLTage {<amplitude>|MINimum|MAXimum}
[SOURce[1|2]:]VOLTage? [{MINimum|MAXimum}]
Sets output amplitude.
320 Agilent 33500 Series Operating and Service Guide
