158 Set Up EtherNet/IP Communication Across Subnets
MSG Parameter Value
Message Type CIP Generic
Service Type Get Attribute Single
Service Code e
Class c0
Instance 1
Attribute 4
Source Element
Source Length
Destination ChasB_RedundancyState
Path
(communication tab)
Specify the 1756-ENBT module in Chassis B. Use either of these
methods:
• Add the module to the I/O configuration of the controller. Then
use the Browse button on the Communication tab to identify
the module.
• Type the path using port numbers and addresses.
To Next Page
