Publication 1756-UM523F-EN-P - December 2006
Configure the System Redundancy Module 55
What to Do Next
Check the Revision of Your
SRM Configuration Tool
Check the revision of your SRM configuration tool to make sure that
you are using the right revision of the SRM configuration tool for your
ControlLogix redundancy system.
Perform this procedure to:
• use the SRM configuration tool for the first time.
• connect to a different ControlLogix redundancy system for the
first time.
• update the firmware of a ControlLogix redundancy system.
Before You Begin
RSLinx software automatically installs the SRM configuration tool. Use
this table to see which revision of the tool that you get.
RSLinx Software Versions
IMPORTANT
Make sure that you check the revision of your SRM
configuration tool before you use it. Later revisions of the SRM
configuration tool are not compatible with earlier revisions of
ControlLogix redundancy systems. See Check the Revision of
Your SRM Configuration Tool on page 55.
IMPORTANT
Make sure that you check the revision of your SRM
configuration tool.
• Revision 2.6 is compatible only with revision 13.x or later
ControlLogix redundancy systems.
• You will cause the 1757-SRM module to fault if you use
revision 2.6 of the tool with an revision 11.x or earlier
redundancy systems.
Software Installed Tool
RSLinx software, version 2.42 SRM configuration tool revision 2.5
RSLinx software, version 2.43 SRM configuration tool revision 2.6
RSLinx software, version 2.52 SRM configuration tool revision 3.6
