Publication 1756-UM523F-EN-P - December 2006
44 Install the System
This chapter provides the sequence of tasks and the critical actions for
the successful installation of a ControlLogix redundancy system. It
does not replace the installation instructions for the components of
the system. During installation, refer to these publications.
Installation Publications
Installation instructions provide important information, such as
detailed installation steps, safety considerations, enclosure
requirements, and hazardous location information.
Before installing the system, review these guidelines for safe handling
of ControlLogix components.
Install this component According to this publication
1756-A4, -A7, -A10, -A13, or -A17 chassis ControlLogix Chassis Installation Instructions, publication 1756-IN080
1756-PA72 or -PB72 power supply ControlLogix Power Supplies Installation Instructions, publication 1756-5.67
1756-PA75 or -PB75 power supply ControlLogix Power Supplies Installation Instructions, publication 1756-5.78
ControlLogix controller ControlLogix Controller and Memory Board Installation Instructions, publication
1756-IN101
1756-CNB/D/E or -CNBR/D/E module ControlLogix ControlNet Bridge Installation Instructions, publication 1756-IN571
1756-ENBT module ControlLogix EtherNet/IP Bridge Module Installation Instructions, publication
1756-IN019
1756-EWEB module EtherNet/IP Web Server Module Installation Instructions, publication 1756-IN588
1757-SRM module ProcessLogix/ControlLogix System Redundancy Module Installation Instructions,
publication 1757-IN092
WARNING
When you insert or remove a module while backplane power is
on, an electrical arc can occur. This could cause an explosion in
hazardous location installations. Be sure that power is removed
or the area is nonhazardous before proceeding.
