Rockwell Automation Publication 2094-UM001J-EN-P - March 2017 185
Remove and Replace the Kinetix 6000 Drive Modules Chapter 8
Replace the Power Rail
This procedure assumes you do not need to change the location of the power
rail on the panel and you intend to reuse the mounting bolts of the power rail
you just removed.
Follow these steps to replace the power rail.
1. Align the replacement power rail over the existing mounting bolts.
2. Tighten the mounting bolts.
3. Reattach the braided grounding strap to the power rail grounding stud
(refer to page 184
).
IMPORTANT If you need to change the location of the power rail, or if you are installing a
power rail designed for additional or fewer modules than you removed, refer
to Kinetix 6000 Power Rail Installation Instructions, publication 2094-IN003
.
ATTENTION: To avoid damage to the power rail during installation, do not
remove the protective covers until the module for each slot is ready for
mounting.
IMPORTANT To improve the bond between the power rail and subpanel, construct your
subpanel out of zinc plated (paint-free) steel.
