Allen-Bradley PanelView Plus 1000 User Manual

1 Publication 2711P-UM001A-EN-P
Appendix A
Specifications
Electrical
Environmental
Display
DC Power
Input Voltage DC
Power Consumption DC
24V dc nominal (18…32V dc)
70 Watts maximum (2.9A @24V dc)
AC Power (2711P-RSAC)
Input Voltage AC
Power Consumption AC
85…264V ac, 47…63 Hz
120VA maximum
Operating Temperature 0…55 °C (32…131 °F)
Non-operating Temperature -25…70 °C (-13 to 158 °F)
Relative Humidity 0…95% without condensation
Shock Operating 15 g at 11 ms
Shock Non-Operating 30 g at 11 ms
Vibration 10…57 Hz, 0.012 pk-pk displacement
57…500 Hz, 2 g pk acceleration
Ratings Nema Type 12, 13, 4X (Indoor use only),
IP54, IP65
Display Type Color Active Matrix TFT Thin-Film Transistor
with LCD Liquid Crystal Display
Display Area Size
700
1000
1250
1500
6.5 inch
10.4 inch
12.1 inch
15.0 inch
Display Area (W x H)
700
1000
1250
1500
132 x 99 mm (6.7 inch diagonal)
211 x 158 mm (10.4 inch diagonal)
246 x 184 mm (12.1 inch diagonal)
304 x 228 mm (15.1 inch diagonal)
Resolution
700
1000
1250
1500
640 x 480
640 x 480
800 x 600
1024 x 768
Touch Technology Analog Resistive
