1 Publication 2711P-UM001A-EN-P
Chapter
3
Applying Power
Chapter Objectives
This chapter provides information:
• wiring and safety guidelines
• connecting DC power
• connecting AC power
• resetting the terminal
• powerup sequence
Wiring and Safety
Guidelines
Use publication NFPA 70E, Electrical Safety Requirements for
Employee Workplaces when wiring the PanelView Plus terminals. In
addition to the NFPA guidelines:
• connect the terminal and other similar electronic equipment to
its own branch circuit.
• protect the input power by a fuse or circuit breaker rated at no
more than 15 Amps.
• route incoming power to the terminal by a separate path from
the communication lines.
• where power and communication lines must cross, they should
cross at right angles.Communication lines can be installed in the
same conduit as low level DC I/O lines (less than 10 volts).
• shield and ground cables appropriately to avoid Electromagnetic
Interference (EMI). Grounding minimizes noise from EMI and is
a safety measure in electrical installations.
For additional grounding recommendations, refer to the National
Electrical Code published by the National Fire Protection Association
of Boston.
