Allen-Bradley PanelView Plus 1000 User Manual

Publication 2711P-UM001A-EN-P
Overview 1-7
Catalog Number
Configuration
The following table shows the catalog number configuration for
PanelView Plus terminals.
Product Components
All of the PanelView Plus components listed in this section are
available as separate catalog numbers for field replacement.
Display Modules
Communication Modules
Input Size Type Comms Power Memory
Flash/RAM
Label
||| | | | |
2711P- K = Keypad 7 = 6.5 inch C = Color 4 = Standard Communication (Ethernet & RS-232) B = AC DIN 1= 32 MB/64 MB Blank =AB Label
T = Touch 10 = 10.4 inch 6 = DH+, DH-485, RIO & Standard Communication D = DC 2 = 128MB/128 MB N = No Label
B = Both 12 = 12.1 inch
15 = 15 inch
Cat. No. Description
2711P-RDK7C 700 Keypad Color Display
2711P-RDT7C 700 Touch Color Display
2711P-RDB7C 700 Keypad and Touch Color Display
2711P-RDK10C 1000 Keypad Color Display
2711P-RDT10C 1000 Touch Color Display
2711P-RDB10C 1000 Keypad and Touch Color Display
2711P-RDK12C 1250 Keypad Color Display
2711P-RDT12C 1250 Touch Color Display
2711P-RDB12C 1250 Keypad and Touch Color Display
2711P-RDK15C 1500 Keypad Color Display
2711P-RDT15C 1500 Touch Color Display
2711P-RDB15C 1500 Keypad and Touch Color Display
Cat. No. Description
2711P-RN6 DH+DH-485/Remote I/O Communication Module
AB PLCs
