A-22 Supplemental Drive Information
Table A.I PowerFlex 700 Frames
6 All
Frame Rating Dimensions
116.6
(4.59)
148.5
(5.85)
222.3
(8.75)
242.0
(9.53)
219.0
(8.62)
185.4
(7.30)
151.8
(5.98)
52.1 (2.05)
69.1 (2.72)
130.1 (5.12)
280.1 (11.03)
330.1 (13.00)
230.1 (9.06)
47.1 (1.85)
45.6 (1.80)
56.2 (2.21)
Removable Junction Box
22.2 (0.87) Dia.
4 Places
62.7 (2.47) Dia.
3 Places
34.9 (1.37) Dia.
3 Places
Frame Cross Reference
Frame
AC Input DC Input
208/240 400V 480V 600V 540V 650V
ND HP HD HP ND kW HD kW ND HP HD HP ND HP HD HP ND HP HD HP ND HP HD HP
0 0.5 0.33 0.37 0.25 0.5 0.33 – – 0.37 0.25 0.5 0.33
1 0.75 0.75 0.55 1 0.75 – – 0.75 0.55 1 0.75
– – 1.5 0.75 2 1.5 – – 1.5 0.75 2 1.5
––2.21.532––2.21.532
––42.253––42.253
––5.547.55––5.547.55
1 2 1.5 7.5 5.5 10 7.5 10 7.5 7.5 5.5 10 7.5
3 2 11 7.5 15 10 15 10 11 7.5 15 10
53––––––––––
7.55––––––––––
2 107.515112015201515112015
– – 18.5152520252018.5152520
3 15 10 22 18.5 30 25 30 25 22 18.5 30 25
20 15 30 22 40 30 40 30 30 22 40 30
– – 37305040504037305040
4 25 20 45 37 60 50 60 50 45 37 60 50
3025––––––––––
5 40 30 55 45 75 60 75 60 55 45 75 60
50 40 – – 100 75 100 75 – – 100 75
6 60 50 75 55 125 100 – – 75 55 125 100
75 60 90 75 150 125 – – 90 75 150 125
– – 110 90 – – – – 110 90 – –
