3-14 Programming and Parameters
Motor Control File
MONITOR
Drive Data
026 [Rated kW]
Drive power rating.
Default:
Min/Max:
Units:
Read Only
0.00/3000.00 kW
0.01 kW
027 [Rated Volts]
The drive input voltage class (208, 240,
400 etc.).
Default:
Min/Max:
Units:
Read Only
0.0/6553.5 VAC
0.0/65535.0 VAC
0.1 VAC
028 [Rated Amps]
The drive rated output current.
Default:
Min/Max:
Units:
Read Only
0.0/6553.5 Amps
0.0/65535.0 Amps
0.1 Amps
029 [Control SW Ver]
Main Control Board software version.
Default:
Min/Max:
Units:
Read Only
0.000/256.256
0.000/65535.000
0.001
196
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
32
Vector
Vector
Vector
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
MOTOR CONTROL
Motor Data
040 [Motor Type]
Set to match the type of motor
connected.
(1)
Important: Selecting option 1 or 2
also requires selection of “Custom V/Hz,”
option 2 in parameter 53.
Default:
Options:
0
0
1
2
“Induction”
“Induction”
“Synchr Reluc”
(1)
“Synchr PM”
(1)
053
041 [Motor NP Volts]
Set to the motor nameplate rated volts.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Volts]
0.1 VAC
042 [Motor NP FLA]
Set to the motor nameplate rated full load
amps.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Amps] × 2
0.1 Amps
047
048
043 [Motor NP Hertz]
Set to the motor nameplate rated
frequency.
Default:
Min/Max:
Units:
Based on Drive Cat. No.
5.0/400.0 Hz
0.1 Hz
044 [Motor NP RPM]
Set to the motor nameplate rated RPM.
Default:
Min/Max:
Units:
1750 RPM
1750.0 RPM
60/2400 RPM
60.0/24000.0 RPM
1 RPM
1.0 RPM
Vector
Vector
Vector
