Allen-Bradley powerflex 700 User Manual

3-12 Programming and Parameters
Monitor File
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
MONITOR
Metering
001 [Output Freq]
Output frequency present at T1, T2 & T3
(U, V & W)
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Freq]
0.1 Hz
002 [Commanded Freq]
Value of the active frequency command.
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
[Commanded Speed]
Value of the active Speed/Frequency
Reference. Displayed in Hz or RPM,
depending on value of [Speed Units].
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
0.1 RPM
079
003 [Output Current]
The total output current present at T1, T2
& T3 (U, V & W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Amps × 2
0.1 Amps
004 [Torque Current]
Based on the motor, the amount of
current that is in phase with the
fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
005 [Flux Current]
Amount of current that is out of phase
with the fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
006 [Output Voltage]
Output voltage present at terminals T1,
T2 & T3 (U, V & W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Volts
0.1 VAC
007 [Output Power]
Output power present at T1, T2 & T3 (U,
V & W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated kW × 2
0.1 kW
008 [Output Powr Fctr]
Output power factor.
Default:
Min/Max:
Units:
Read Only
0.00/1.00
0.01
009 [Elapsed MWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/214748352.0 MWh
0.1 MWh
010 [Elapsed Run Time]
Accumulated time drive is outputting
power.
Default:
Min/Max:
Units:
Read Only
0.0/214748352.0 Hrs
0.1 Hrs
Standard
Vector
32
32
