Selecting Your Hardware Components 39
Procedure
1. For each slot of the chassis that contains a module, list the slot number, the catalog number of the module, and its 5V and 24V maximum currents. Also
include the power consumption of any peripheral devices that may be connected to the processor other than a DTAM or PIC device—the power
consumption of these devices is accounted for in the power consumption of the processor.
Chassis Number 1 Maximum Currents Chassis Number 2 Maximum Currents
Slot Number Cat. No. at 5V dc at 24V dc Slot Number Cat. No. at 5V dc at 24V dc
Slot 0 1747-L511 0.090 A 0.000 A Slot 0 1747-L514 0.090 A 0.000 A
Slot 1 1746-IV8 0.050 A - Slot 1 1746-OW16 0.170 A 0.180 A
Slot 2 1746-OB8 0.135 A - Slot 2 1746-NO4I 0.055 A 0.195 A
Slot 3 1746-OA16 0.370 A - Slot 3 1746-NO4I 0.055 A 0.195 A
Slot Slot 4 1746-NO4I 0.055 A 0.195 A
Slot Slot 5 1746-NO4I 0.055 A 0.195 A
Slot Slot 6 1746-IO12 0.090 A 0.070 A
Slot Slot
Peripheral Device 1747-AIC - 0.085 A Peripheral Device 1747-AIC - 0.085 A
Peripheral Device Peripheral Device
2.Add the loading currents of all the system
devices at 5 and 24V dc to determine the
Total Current.
0.645 A 0.085 A
2.Add the loading currents of all the system
devices at 5 and 24V dc to determine the
Total Current.
0.570 A 1.115 A
3.For 1746-P4 power supplies, calculate the total power consumption of all system devices. If you are not using a 1746-P4 power supply, go to step 4.
Current Multiply by = Watts Current Multiply by = Watts
Total Current at 5V dc 0.645 A 5V 3.225 W Total Current at 5V dc 0.570 A 5V 2.850 W
Total Current
at 24V dc
0.085 A 24V 2.040 W Total Current
at 24V dc
1.115 A 24V 26.76 W
User Current
at 24V dc
0.500 A 24V 12.00 W User Current
at 24V dc
0.500 A 24V 12.00 W
Add the Watts values to determine Total Power
(cannot exceed 70 Watts)
17.26 W Add the Watts values to determine Total Power
(cannot exceed 70 Watts)
41.61 W
4.Choose the power supply from the list of catalog numbers shown below. Compare the Total Current required for the chassis with the Internal Current
capacity of the power supplies. Be sure that the Total Current consumption for the chassis is less than the Internal Current Capacity for the power
supply, for both 5V and 24V loads.
Cat. No. Internal Current
Capacity
Cat. No. Internal Current
Capacity
at 5V dc at 24V dc at 5V dc at 24V dc
1746-P1 2.0 A 0.46 A 1746-P1 2.0 A 0.46 A
1746-P2 5.0 A 0.96 A 1746-P2 5.0 A 0.96 A
1746-P3 3.6 A 0.87 A 1746-P3 3.6 A 0.87 A
1746-P4 (see step 3) 10.0 A 2.88 A 1746-P4 (see step 3) 10.0 A 2.88 A
1746-P5 5.0 A 0.96 A 1746-P5 5.0 A 0.96 A
1746-P6 5.0 A 0.96 A 1746-P6 5.0 A 0.96 A
1746-P7
(1)
12V dc input 2.0 A 0.46 A
1746-P7
(1)
12V dc input 2.0 A 0.46 A
24V dc input 3.6 A 0.87 A 24V dc input 3.6 A 0.87 A
Required Power Supply 1746-P1 Required Power Supply 1746-P4
(1)
See 1746-P7 current capacity graph on page 37.
