NetLinx Programming
82
NX-Series Controllers - WebConsole & Programming Guide
NetLinx Programming
Overview
This section describes the Send_Commands, Send_Strings, and Channel commands you can use to program the Master. The
examples in this section require a declaration in the DEFINE_DEVICE section of your program to work correctly.
Refer to the NetLinx Programming Language instruction manual for specifics about declarations and DEFINE_DEVICE information.
NOTE: All file names on the X-Series controllers are case sensitive. This includes all user f iles created or used within NetLinx or Java
code. If you have legacy code that uses files, it is important that you verify that every reference to each file is consistent with regard
to case. If your legacy code generates an error when accessing a file, it is likely due to inconsistent use of case in the f ilename.
Port Assignments by NetLinx Master
The following table lists the port assignments for NetLinx Masters:
Port Assignments by All-in-One-Presentation Switcher
The following table lists the port assignments for Enova All-in-One Presentation Switchers:
Port Assignments by Massio ControlPad
The following table lists the port assignments for Massio ControlPads:
Port Assignments By Master
Master RS-232 RS-232/422/485 IR/Serial IR/RX Relays I/O PoE
NX-1200 Port 2 Port 1 Ports 11-12 Port 20 N/A Port 22 N/A
NX-2200 Ports 2-4 Port 1 Ports 11-14 N/A Port 21 Port 22 N/A
NX-3200 Ports 2-4, 6-8 Ports 1, 5 Ports 11-18 N/A Port 21 Port 22 N/A
NX-4200 Ports 2-4, 6-8 Ports 1, 5 Ports 11-18 N/A Port 21 Port 22 Ports 24-27
Port Assignments By Enova All-in-One Presentation Switcher
Master RS-232 RS-232/422/485 IR/Serial Relays I/O
DVX-22xxHD Ports 2-4 Port 1 Ports 11-14 Port 21 Port 22
DVX-325xHD Ports 2-4, 6-8 Ports 1, 5 Ports 11-18 Port 21 Port 22
Port Assignments By ControlPad
ControlPad RS-232 IR/Serial Relays I/O NetLinx
MCP-106 Port 1 Port 11 N/A N/A Port 28
MCP-108 Ports 1-2 Ports 11-12 Port 21 Port 22 Port 28
