Asus P5BV-M User Manual

xi
P5BV-M specications summary
(continued on the next page)
Processor / System Bus 1 * Socket LGA775
Intel® CoreTM 2 Duo
Dual-Core Intel® Xeon® 3000 sequence
Quad-Core Intel® Xeon® 3200 sequence
Dual Core/Quad Core
FSB 800/1066/1333MHz EM64T, EIST, VT
Core Logic Intel® 3200 Memory Contoller Hub (MCH)
Intel® ICH7R I/O Controller HUB (ICH)
Form Factor u ATX, 9.6” * 9.6”
ASUS
Features
Smart Fan Smart Fan I- Thermal Cruise Mode
Rack Ready
(Rack and
Pedestal dual
use)
V
ASWM2.0 V
Memory Total Slots 4 (2-channel)
Capacity Maximum up to 8GB
Memory Type DDR2 667 / 800 Unbuffered , ECC / Non
ECC
Memory Size 256MB, 512 MB, 1 GB, 2GB
Expansion
Slots
(follow SSI
Loacation #)
Total PCI/PCI-
X/PCI-E Slots
4
Slot Loacation 4 1 * PCI 32bit/33 MHz
Slot Loacation 5 1 * PCI 32bit/33 MHz
Slot Loacation 6 1 * PCI-E x8 (x8 link, PCIE2 slot)
Slot Loacation 7 1 * PCI-E x8 (x4 link, PCIE1 slot)
Additional Slot 1 1 * SO-DIMM socket for optional ASMB3-
SOL/ASMB3-iKVM
Storage IDE Controller Intel® ICH7R:
1 * IDE support UltraATA 33 / 66 / 100
SATA Controller Intel® ICH7R:
4 SATA2 300MB/s ports
Intel Matrix Storage (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI® MegaRAID (for Linux/Windows)
(Support software RAID 0, 1& 10)
Networking LAN 2 * Broadcom® BCM5721 PCI-E GbE LAN
