Asus P8Z77-V LK2 User Manual

ASUS P8Z77-V LK2
4-11
Chapter 4
• Select From EPU Installation to show the CO2 that has been reduced since you
installed EPU.
• *Select
From the Last Reset to show the total CO2 that has been reduced since you
click the Clear button .
• Refer to the software manual in the support DVD or visit the ASUS website at www.
asus.com for detailed software conguration.
4.3.4 EPU
EPU is an energy-processing utility that provides several power-saving modes. When set
to the Auto Mode, the system automatically changes its power-saving mode based on the
current system condition.
You can also congure the system settings such as CPU frequency, GPU frequency, vCore
Voltage, and Fan Control to customize a power-saving mode.
Launching EPU
To launch EPU, click Tool > EPU on the AI Suite II main menu bar.
*Shifts between the display
of Total and Current CO2
reduced
Displays the system
properties of each mode
Displays the following message
if no VGA power saving engine is
detected.
Advanced settings for each mode
Multiple system
operating modes
The items lighting up
means power saving
engine is activated
Displays the amount of CO2
reduced
Displays the current
CPU power

Asus P8Z77-V LK2 Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4 x DIMM
Max Memory	32 GB
Memory Type	DDR3
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
Form Factor	ATX
Memory Speed	1600/1333 MHz
PCI Express x16	2
USB 2.0 Ports	4 rear
LAN	Realtek 8111F
Audio	Realtek ALC892, 8-Channel High Definition Audio
Video Outputs	HDMI, DVI, VGA
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
