Asus P8Z77-V LK2 User Manual

xii
Package contents
Check your motherboard package for the following items.
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
User Manual
ASUS P8Z77-V LK2 motherboard User Guide
Support DVD 2 x Serial ATA 6.0 Gb/s cables 1 x I/O shield
P8Z77-V LK2

Asus P8Z77-V LK2 Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4 x DIMM
Max Memory	32 GB
Memory Type	DDR3
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
Form Factor	ATX
Memory Speed	1600/1333 MHz
PCI Express x16	2
USB 2.0 Ports	4 rear
LAN	Realtek 8111F
Audio	Realtek ALC892, 8-Channel High Definition Audio
Video Outputs	HDMI, DVI, VGA
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology

Summary

Safety Information

Electrical Safety

Precautions to prevent electrical hazards during system handling and relocation.

Operation Safety

Guidelines for safe handling and operation of motherboard components to prevent damage.

Product Introduction

Special Features

Overview of key motherboard features and technologies.

LucidLogix Virtu MVP

Motherboard Overview

Before You Proceed

Motherboard Layout

Intel® CPU Socket

DDR3 DIMM Sockets

System Memory

Memory Configurations

Expansion Slots

Jumpers

Intel® Z77 Serial ATA 6.0 Gb/s Connectors

USB 2.0 Connectors

Front Panel Audio Connector

CPU, Chassis, and Power Fan Connectors

USB 3.0 Connector

Intel® Z77 SATA 3.0 Gb/s Connectors

ATX Power Connectors

System Panel Connector

Basic Installation

Building Your PC System

Steps for assembling the PC system.

Motherboard Installation

Instructions for installing the motherboard into the PC chassis.

CPU Installation

DIMM Installation

ATX Power Connection

SATA Device Connection

Expansion Card Installation

Motherboard Rear and Audio Connections

Rear I/O Connection

Starting Up for the First Time

BIOS Setup

Knowing BIOS

BIOS Setup Program

How to enter and navigate the BIOS setup.

Security

Administrator Password

User Password

Ai Tweaker Menu

Configuration for overclocking-related items.

CPU Voltage

Set fixed or offset CPU voltage.

DRAM Voltage

Set DRAM voltage.

Advanced Menu

CPU Configuration

PCH Configuration

SATA Configuration

Set SATA mode to IDE, AHCI, or RAID.

System Agent Configuration

Monitor Menu

CPU Temperature / MB Temperature

Boot Menu

Boot Option Priorities

Tools Menu

Configure options for special functions.

ASUS EZ Flash 2 Utility

Update BIOS using a USB flash drive.

ASUS CrashFree BIOS 3 Utility

Auto recovery tool for corrupted BIOS.

Exit Menu

Load defaults, save, or discard changes.

Load Optimized Defaults

Load default BIOS parameters.

Save Changes & Reset

Save selections and reset system.

Updating BIOS

ASUS Update Utility

Manage, save, and update BIOS in Windows.

Updating the BIOS Through the Internet

Step-by-step guide to update BIOS via internet.

Updating the BIOS Through a BIOS File

Step-by-step guide to update BIOS from a file.

Software Information

AI Suite II

All-in-one interface for ASUS utilities.

TurboV EVO

Manually adjust CPU frequency and voltages.

GPU Boost

Overclock integrated iGPU for graphics performance.

DIGI+ VRM

Adjust VRM voltage and frequency modulation.

EPU

Energy processing utility for power-saving modes.

FAN Xpert+

Adjust CPU and chassis fan speeds.

Probe II

Utility to monitor vital components and alerts.

Sensor Recorder

Monitor system voltage, temp, fan speed over time.

USB 3.0 Boost

Increase USB 3.0 transfer speed with UASP.

Ai Charger

Network iControl

Manage network bandwidth and auto PPPoE connection.

ASUS Update

Manage, save, and update BIOS in Windows.

MyLogo2

Customize the boot logo.

Audio Configurations

Details about Realtek audio CODEC and software.

RAID Support

RAID Configurations

Overview of supported SATA RAID solutions.

RAID Definitions

Explanation of RAID 0, 1, 5, and 10 configurations.

Installing Serial ATA Hard Disks

Setting the RAID Item in BIOS

How to enable RAID function in BIOS Setup.

Intel® Rapid Storage Technology Option ROM Utility

Creating a RAID Set

Step-by-step guide to create a RAID set.

Deleting a RAID Set

Instructions for deleting a RAID set.

Creating a RAID Driver Disk

Creating a RAID Driver Disk Without Entering the OS

Creating a RAID Driver Disk in Windows®

Installing the RAID Driver During Windows® OS Installation

Using a USB Floppy Disk Drive

Intel® Technologies

Introduction to Intel® 2012 Desktop Responsiveness Technologies

System Requirements for Intel® 2012 Desktop Responsiveness Technologies

Intel® Smart Response Technology

Intel® Rapid Start Technology

Creating a Partition

Steps to create a partition for Rapid Start Technology.

Enabling and Disabling the Intel® Rapid Start Technology Under the OS

Recovering the Partition

Intel® Smart Connect Technology

Multiple GPU Support

AMD® CrossFireX™ Technology

Allows installation of multi-GPU graphics cards.

Requirements

Before You Begin

Installing Two CrossFireX™ Graphics Cards

Installing the Device Drivers

Enabling the AMD® CrossFireX™ Technology
