Asus P8Z77-V LK2 User Manual

1-6
Chapter 1: Product introduction
Chapter 1
Chapter 1
Chapter 1
Chapter 1
Layout contents
Connectors/Jumpers/Slots/LED Page
1. CPU, Chassis and power fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1/2, 3-pin PWR_FAN)
1-23
2. EATX power connectors (24-pin EATXPWR, 4-pin EATX12V) 1-26
3. Intel
®
CPU socket
4. DDR3 DIMM sockets 1-7
5. USB 3.0 connector (20-1 pin USB3_34) 1-24
6. Intel
®
Z77 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1–4 [blue]) 1-25
7. Onboard LED (SB_PWR) 1-19
8. Intel
®
Z77 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1/2 [gray]) 1-20
9. System panel connector (10-1 pin F_PANEL) 1-24
10. Speaker connector (4-pin SPEAKER) 1-28
11. USB 2.0 connectors (10-1 pin USB56, USB78) 1-21
12. Clear RTC RAM (3-pin CLRTC) 1-18
13. Direct connector (2-pin DRCT) 1-28
14. Serial port connectors (10-1 pin COM) 1-19
15. Digital audio connector (4-1 pin SPDIF_OUT) 1-22
16. Front panel audio connector (10-1 pin AAFP) 1-22

Asus P8Z77-V LK2 Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4 x DIMM
Max Memory	32 GB
Memory Type	DDR3
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
Form Factor	ATX
Memory Speed	1600/1333 MHz
PCI Express x16	2
USB 2.0 Ports	4 rear
LAN	Realtek 8111F
Audio	Realtek ALC892, 8-Channel High Definition Audio
Video Outputs	HDMI, DVI, VGA
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
