Asus P8Z77-V LK2 User Manual

ASUS P8Z77-V LK2
1-5
Chapter 1
Chapter 1
Chapter 1
Chapter 1
1.2.2 Motherboard layout
Refer to 2.2.1 Rear I/O connection for more information about rear panel connectors.
P8Z77-V LK2
PCIEX16_1
PCIEX16_2
PCIEX1_2
PCIEX1_1
PCI1
PCI2
USB78 USB56
USB3_34
SPDIF_OUT
AAFP
CPU_FAN
CHA_FAN2
CHA_FAN1
PWR_FAN
Lithium Cell
CMOS Power
Super
I/O
DIGI
+VRM
ASM
1442
RTL
8111F
COM1
8Mb
BIOS
SB_PWR
SATA3G_3 SATA3G_2 SATA3G_1
SATA3G_4 SATA6G_2 SATA6G_1
CLRTC
20.8cm(8.2in)
30.5cm(12.0in)
Intel
®
Z77
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module)
ASM
1083
ALC
887
EATXPWR
LGA1155
AUDIO
KBMS
LAN_USB12
LAN3_12
USB34
HDMI
F_PANEL
SPEAKER
DRCT
VGA
ATX12V
1 12 43
2
15 1416 111213 89 610
5
6
7

Asus P8Z77-V LK2 Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4 x DIMM
Max Memory	32 GB
Memory Type	DDR3
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
Form Factor	ATX
Memory Speed	1600/1333 MHz
PCI Express x16	2
USB 2.0 Ports	4 rear
LAN	Realtek 8111F
Audio	Realtek ALC892, 8-Channel High Definition Audio
Video Outputs	HDMI, DVI, VGA
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
