Asus P8Z77-V LK2 User Manual

ASUS P8Z77-V LK2
5-3
Chapter 5
5.1.4 Intel
®
Rapid Storage Technology Option ROM utility
To enter the Intel
®
Rapid Storage Technology Option ROM utility:
1. Turn on the system.
2. During POST, press <Ctrl> + <I> to display the utility main menu.
The navigation keys at the bottom of the screen allow you to move through the menus
and select the menu options.
The RAID BIOS setup screens shown in this section are for reference only and may not
exactly match the items on your screen.
The utility supports maximum four hard disk drives for RAID conguration.
Intel(R) Rapid Storage Technology - Option ROM - v10.5.1.1070
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
[ DISK/VOLUME INFORMATION ]
RAID Volumes:
None defined.
Physical Devices:
Port Device Model Serial # Size Type/Status(Vol ID)
0 ST3160812AS 9LS0HJA4 149.0GB
1 ST3160812AS 9LS0F4HL 149.0GB
2 ST3160812AS 3LS0JYL8 149.0GB
3 ST3160812AS 9LS0BJ5H 149.0GB
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-
4. Recovery Volume Options
5. Acceleration Options
6. Exit
Non-RAID Disk
Non-RAID Disk
Non-RAID Disk
Non-RAID Disk

Asus P8Z77-V LK2 Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Slots	4 x DIMM
Max Memory	32 GB
Memory Type	DDR3
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
Form Factor	ATX
Memory Speed	1600/1333 MHz
PCI Express x16	2
USB 2.0 Ports	4 rear
LAN	Realtek 8111F
Audio	Realtek ALC892, 8-Channel High Definition Audio
Video Outputs	HDMI, DVI, VGA
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
