Atlas Copco GA 75+ User Manual

4.17 User password menu
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Menu icon, Password
Function
If the password option is activated, it is impossible for not authorized persons to modify any setting.
Procedure
Starting from the Main screen (see Main screen),
• Move the cursor to <Menu> and press the Enter key (2). Following screen appears:
• Using the Scroll keys, select the <Settings> icon (see section Modifying general settings)
• Press the Enter key. Following screen appears:
Instruction book
2920 7109 60 109

Atlas Copco GA 75+ Specifications

General

Model	GA 75+
Category	Air Compressor
Power	75 kW
Capacity FAD	13.5 m³/min
Working Pressure	7.5-13 bar
Noise Level	70 dB(A)
Cooling System	Air Cooled
Drive Type	Direct Drive
