Autronica SM4 User Manual

SM4 Manual by MRM-Racing V3.0
110
NOTE2:
When ECU is password protected, some live data parameters will read zero.
PC Logger setup
Sets up the PC logger rate, trigger and memory model.
F8 always overrides the trigger (Turns PC logger ON or OFF, independent to what the
trigger is. However the trigger will take control again when crossing the trigger threshold)
When logger full, will override oldest data in a circle buffer arrangment.
Select items to log under "PC warnings & select" menu.
NOTE
To save the PC logged data, press F10 which opens a graph window. Save graphed
data under "Edit-Window", "Save logged file" menu.
PC logger Control
Manual control of the PC logger.
F8 always overrides the trigger (Turns PC logger ON or OFF, independent to what the
trigger is. However the trigger will take control again when crossing the trigger threshold)
When logger full, will override oldest data in a circle buffer arrangment.
Select items to log under "PC warnings & select" menu.
Status of PC logger is on bottom left of screen.
PC Logger
Armed
Read to start logging
Running
Logger is running.
NOTE
To save the PC logged data, press F10 which opens a graph window. Save graphed
data under "Edit-Window", "Save logged file" menu.
PC Error history
When errors are flashed at top right of screen, they are recorded so can be viewed later.
The last error of the family is always recorded along with the time stamp.
Can check at end of a dyno run to see which errors were recorded or to see errors that
were not seen. See also "M0,ECU error history" for more detailed in ECU errors.
PC Logger setup
Sets up the PC logger rate, trigger and memory model.
F8 always overrides the trigger (Turns PC logger ON or OFF, independent to what the
trigger is. However the trigger will take control again when crossing the trigger threshold)
When logger full, will override oldest data in a circle buffer arrangement.
Select items to log under "PC warnings & select" menu.
• To save the PC logged data, press F10 which opens a graph window. Save
graphed data under "Edit-Window", "Save logged file" menu.
PC Logger control
Manual control of the PC logger.
