Up/Down arrow keys then adjust time in an XY strip chart which is how long it goes back
through the logged data.
Zoom in/out
“Up/Down” key
Zooms graph in/out. Works in default time steps
Lines 1..4 on 1 plot
“1” key
Can select a single item to plot. If want to zoom all items plotted on line 3 to a single line
then can do it here.
Lines 1..2
“2” key
Plots data points that are specified in the Colors/ranges menu that are on line 2 or
displays line 1 and line 2 on the graph. You toggle between the two modes by pressing 2.
Makes it easy to zoom line you want to full screen quickly.
Lines 1..3
“3” key
Plots data points that are specified in the Colors/ranges menu that are on line 3 or
displays line 1,line 2 and line 3 on the graph. You toggle between the two modes by
pressing 3. Makes it easy to zoom line you want to full screen quickly.
Lines 1..42
“4” key
Plots data points that are specified in the Colors/ranges menu that are on line 4 or
displays line 1,line 2,line 3 and line 4 on the graph. You toggle between the two modes
by pressing 4. Makes it easy to zoom line you want to full screen quickly.
Graph color/spans
Options.
1. Select items to display on the graph (Space bar).
2. Set minimum and maximum graph or instrument ranges for graphing or virtual drive
(Press enter on selected item).
3. Set the line you want to graph to when graphing (Press enter on selected item).
4. Sets the color for graphing (Press enter on selected item).
Keys: Enter = Set edit limits.
Space = Select item to graph.
5. To save changes press enter & select "Save new settings" item.
• In virtual drive, "Space bar" graph select does not work. To graph an item you
create a strip chart.
• Limits adjusted here has no effect on the "PC warnings & selection" menu.
