• Mass Storage - Select this checkbox to establish a virtual media mass-storage connection
to a device. Clear this checkbox to end the connection.
• Write Access - Select this checkbox to enable the connected device to write data to the
virtual media during a virtual media session. Read access is always enabled during virtual
media sessions.
6. Click O K .
3.2 Setup Dialog Box Functions
You can configure your switch system from the Setup dialog box within the OSCAR interface. Select the
N a m es button when initially setting up your switch to identify devices by unique names. Select the other
setup features to manage routine tasks for your devices from the OSCAR interface menu. The following
table lists the functions accessed using each of the buttons in the Setup dialog box.
To access the OSCAR interface Setup dialog box, click Setu p on the Main dialog box.
FEATURE PURPOSE
Menu
Change the Main dialog box list sorting option by toggling numerically between port number, EID number or alphabetically by name.
Change the Screen Delay Time before the OSCAR interface displays after pressing Print Screen. You can also change how the OSCAR
interface activation sequence is invoked.
Security Set passwords to protect or restrict access or enable the window saver.
Devices Identify the appropriate number of ports on an attached tiered switch.
Names Identify devices by unique names.
Keyboard Set the keyboard country code value for the USB devices.
Broadcast Set up to simultaneously control multiple devices through keyboard and mouse actions.
Switch Change how local port connections are managed by the switch. Control Local to Local Share Mode.
Network Choose your network speed, transmission mode and configuration.
Scan Set up a custom Scan pattern for multiple devices.
VMedia Set the behaviour of the switch during a virtual media session.
Table 3.4 Setup Dialog Box Features
3.2.1 Changing the display behavior
Use the Men u dialog box to change the order of displayed devices, change how the OSCAR interface is
invoked or set a Screen Dela y T im e for the OSCAR interface. This setting alters how devices are displayed
in several dialog boxes, including the Main , Devic es and Scan L ist boxes.
To access the OSCAR interface Men u dialog box, activate the OSCAR interface and click Setu p - Men u in
the M ain dialog box.
To choose the display order of devices:
1. Select N am e to display devices alphabetically by name.
-or-
Select EID to display devices numerically by EID number.
-or-
Select Port to display devices numerically by port number.
Vertiv | Avocent® AutoView™ 2108/2216/3108/3216 Switch Installer/User Guide | 19
