Bay-Tek CONNECT 4 HOOPS User Manual

57
PART # DESCRIPTION PART # DESCRIPTION
PARTS LIST
94639A207 Spacer, Nylon 1/4"Od,5/16"Lg,#4
A5BA15000 Basketball W/Logo, Mini, Size 3
AABK1013 Bracket, Pushbutton/Counters
A5BK9999 Bracket, Power Supply Mounting
A5CB2050 Coin Box, Black Plastic Cash Box
A5FI9010 Filter, F1700ca06, Inline
A5HA1200 Handle, Cash Box, White Plastic
A5HO1003 Holder For Light Bars
A5KIT-HOOPSHD Hardware Kit, C4 Hoops HD
A5LK2001 Lock, Cash Box, A05/E00 Key Code
A5LK5002 Lock, 7/8", H95 Key Code
A5LV10000 Levelers, C4 Hoops Cabinet
A5OU5000 Outlet Strip, Four Positions
A5PL4200 Plate, Upstacker Bill Acceptor Plate
A5PL8900 Plate, Bill Validator Blanking Plate
A5SLLO020 1/4" Bore, Shaft Collar 3/32" Allen
A5SP10000 Spring, Extension, 7/16 X 2-3/4
A5SREX050 Spring,6",3/8"Od,.041"
AASW200 Low Ticket Switch
A5TG15000 Tempered Glass, 3/16" X 33.56" X 58.38"
A5VF4604 Vacuum Form, Cup Holder
AACO1020 Counter Assy
W5HG1025 Hinge,16",Double Bend
W5HG1030 Hinge,23",Single Bend
W5HG1040 Hinge,8-3/8"Single Bend
W5HG1065 Hinge, 5-75, Single Bend
W5KE5000 Keeper, Lock
W5TM4000 T-Mold,7/8"Black
A5DE15000 Decal, Speaker Panel, Polycarb
A5DE15001 Decal, Backboard, Polycarb
A5DE15002 Decal, Cabinet Front
A5DE15003 Decal, Left Ticket Door Decal
A5DE15004 Decal, Right Ticket Door Decal
A5DE15005 Decal, Cash Box Door Decal
A5DE15006 Decal, Mech Door Left, Red
A5DE15007 Decal, Mech Door Right, Yellow
A5DE15008 Decal, Left Red Platform With Caution
A5DE15009 Decal, Right Yellow Platform W Caution
A5DE15010 Decal, Cab Side Top Left
A5DE15011 Decal, Cab Side Bottom Left
A5DE15012 Decal, Cab Side Top Right
A5DE15013 Decal, Cab Side Bottom Right
A5DE15020 Decal, Left Red Shelf Decal
A5DE15014-1 Decal, Cab Side Left Bottom Panel
A5DE15014-2 Decal, Cab Side Left Top Panel
A5DE15021 Decal, Right Yellow Shelf Decal
A5DE15015-1 Decal, Cab Side Right Bottom Panel
A5DE15015-2 Decal, Cab Side Right Top Panel
A5DE15016 Decal, Front Cover, Plexi PETG
A5DE15019 Decal, Marquee, Polycarb
A5DE10021 Decal, Caution, Ball Trough
A5ME10001 Metal, Top Lock Bracket
A5ME10008 Metal, Center Side Guard
A5ME10016 Metal, Right Coin Guide
A5ME10017 Metal, Left Coin Guide
A5ME10018 Metal, Cage Panel Bracket
AAME15019 Metal, Side Cages
A5ME15000 Metal, Marquee Mount
A5ME15001 Metal, Top Front Cab. Connector Plate
A5ME15002 Metal, Front Side Rail
A5ME15003 Metal, Front Rail
A5ME15004 Metal, Side Cab. Connector
A5ME15005 Metal, New Tray Insert
A5ME15006 Metal, Lift Gate
A5ME15007 Metal, Back Side Rail
A5ME15008 Metal, Window Rail Mount
A5ME15009 Metal, Light Bracket
A5ME15010 Metal, Back Cab. Top Connector
A5ME15011 Metal, Top Rail
A5ME1727 Metal, Motor Bracket
A5ME4179 Metal, Ticket Tray Bracket
A5CBL4A-DOOR Cable, Double Coin Door
A5CBL5900 Cable, USB, Male A To Male Micro
A5CE2300 Cable, Audio Isolator
A5CE6601 CABLE,USB,6',EXTENSION,Black
A5CEAU010 Cable, Audio Stereo,3.5mm
A5CORD1 Cord,Power,10'
A5CORD23 Cord,10' USB,A Male To A Female
A5CORD36 Cord, 8' HDMI To HDMI
A5CORD37 Cord, 15' Male To Female HDMI
A5CORD50 Cord, Power, 3ft
A5CORD51 Cord, HDMI, 6ft, Male To Female
A5CORD5-A Cord, Ac Computer Cord
AALB15000 Cable Assy, 1st Hoop Addressable Board
