Install passenger seat ( 63).
Removing and installing
front turn indicator
Removing front turn
signal
NOTICE
The working steps described
here for the right fairing side
panel also apply logically for the
left side.
Removing the right-hand cover
panel ( 160).
Remove screw 1 and remove
turn signal. Guide cable
through the fairing side panel.
Protect vehicle connec-
tors against contamination.
Installing right-hand cover panel
( 161).
Installing front turn signal
Removing the right-hand cover
panel ( 160).
Guide cable through the fairing
side panel.
Fit turn signal and install
screw 1.
Installing right-hand cover panel
( 161).
7
115
z On the racetrack

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
