BMW S 1000R 2018 User Manual

Squeeze locking levers to-
gether and remove lid of the
fuse box 1.
To replace main fuse, remove
lid 2 of the relay box.
Pull faulty fuse up and out of
fuse box.
NOTICE
If the fuses blow frequently, have
the electrical system checked by
an authorized specialized work-
shop, preferably an authorized
BMW Motorrad retailer.
Replace fuse
Replace faulty fuse with a fuse
with the required current level.
NOTICE
An overview of the fuse assign-
ment and the required amper-
ages is provided in the chapter
"Technical Data". The numbers
in the graphic match the fuse
numbers.
Close fuse cover.
Locking mechanism audibly
engages.
Install passenger seat ( 63).
Data link connector
Removing the diagnostic
connector
CAUTION
Incorrect procedure followed
when disconnecting the data
link connector for the On-
Board Diagnostics.
Motorcycle experiences malfunc-
tions
Only have the data link con-
nector disconnected by a spe-
cialist workshop or other autho-
rized persons during your next
BMW Service appointment.
Have the work performed by
appropriately trained staff.
Refer to the vehicle manufac-
turer specifications.
Remove passenger seat
( 62).
9
165
z Maintenance

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
