BMW S 1000R 2018 User Manual

Press light source into socket.
Press license-plate light 1 into
light housing.
Diode taillight
If more tail light LEDs have failed
than specified below, the tail light
must be replaced. In this case:
Contact an authorized service
facility, preferably an authorized
BMW Motorrad retailer.
Maximum number of de-
fective LEDS in the tail-
lamp
1
Fairings and panels
Removing right fairing
side panel
NOTICE
The working steps described
here for the right fairing side
panel also apply logically for the
left side.
Switch off ignition ( 45).
with engine spoiler
OE
Remove screws 1.
Loosen retaining hook 2 and
remove engine spoiler 3.
Remove screws 1.
9
158
z Maintenance

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
