BMW S 1000R 2018 User Manual

Threaded fasteners
Front wheel Value Valid
Quick-release axle in threaded
bush
M24 x 1.5 37 lb/ft (50 Nm)
Clamping screw in axle adapter
M8 x 35 Tightening sequence: Tighten the
screws 6 times, alternating between one
and the other each time
14 lb/ft (19 Nm)
Radial brake calipers on the axle
adapter
M10 x 65 28 lb/ft (38 Nm)
Rear wheel Value Valid
Locknut of drive-chain tension-
ing screw
M8 14 lb/ft (19 Nm)
12
177
z Technical data

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
