Fasten brake line in holder 2
and install screw 1.
Adjusting chain tension
( 167).
Light sources
Replacing low-beam light
source in headlight
NOTICE
The alignment of the connector
may vary from the illustration de-
pending on the light source to be
replaced.
Switch off ignition ( 45).
Removing the right-hand cover
panel ( 160).
Remove screws 1 and tilt the
right headlamp slightly to the
side.
Remove cover 1.
Disconnect the plug 1.
9
151
z
Maintenance

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BMW S 1000R 2018 and is the answer not in the manual?

BMW S 1000R 2018 Specifications

General IconGeneral
Torque114 Nm at 9, 250 rpm
ABSStandard
Traction ControlStandard
Power165 hp (121 kW) at 11, 000 rpm
Transmission6-speed constant mesh
Rear SuspensionAluminum swing arm, adjustable compression and rebound damping
Front BrakeDual 320mm discs, 4-piston calipers
Rear BrakeSingle disc brake, diameter 220 mm, single-piston floating caliper
Seat Height814 mm
Fuel Capacity17.5 liters
Weight205 kg (wet weight)
Front SuspensionUpside-down telescopic fork, adjustable compression and rebound damping
