BMW S 1000R 2018 User Manual

Adjust clutch lever play
To increase clutch play: turn
the screw 1 into handlebar fit-
ting.
To decrease clutch play: turn
the screw 1 out of handlebar
fitting.
Check clutch lever play
( 140).
Repeat these operations until
the clutch play is correctly ad-
justed.
Coolant
Checking coolant level
Park motorcycle, ensuring that
support surface is firm and
level.
Read off coolant level on ex-
pansion tank 1. Direction of
view: from front looking at
outer side of right-hand side
trim panel.
Required coolant level
between MIN and MAX
marks on the expansion tank
(Engine cold)
If coolant level drops below ap-
proved level:
Add coolant.
Topping up coolant
Removing fairing side panel
( 158).
9
141
z Maintenance

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
