Bosch CL Series User Manual

Specification Tables
20.3 Compressor Characteristics
Table 20 Compressor Characteristics
Model
Voltage
Code
Cold Winding Resistance Values (+/-7%)
Run
Capacitor
(μF/V)
Single Phase Three Phase
R-C S-C T1–T2 T2–T3 T3–T1
CL007
208—230/1/160 5.50 6.64 — — — 15µF/370V
265/1/60 7.84 5.59 — — — 15µF/440V
CL009
208–230/1/60 3.78 2.91 — — — 25µF/370V
265/1/60 4.30 4.27 — — — 20µF/440V
CL012
208—230/1/60 2.84 1.96 — — — 35µF/370V
265/1/60 3.67 2.96 — — — 30µF/440V
CL015
208–230/1/60 2.60 2.28 — — — 40µF/370V
265/1/60 3.04 3.18 — — — 30µF/440V
CL018
208–230/1/60 1.97 1.42 — — — 50µF/440V
265/1/60 2.54 1.87 — — — 30µF/440V
CL024
208–230/1/60 1.18 1.61 — — — 55µF/440V
265/1/60 2.44 2.23 — — — 40µF/440V
208–230/3/60 — — 1.59 —
460/3/60 — — 6.079 —
CL030
208–230/1/60 1.110 1.060 — — — 60µF/440V
265/1/60 1.176 1.661 — — — 35µF/440V
208–230/3/60 — — 1.423 —
460/3/60 — — 4.565 —
CL036
208–230/1/60 0.719 1.431 — — — 40µF/370V
265/1/60 0.888 1.342 — — — 45µF/370V
208–230/3/60 — — 0.975 —
460/3/60 — — 4.266 —
CL042
208–230/1/60 0.568 1.636 — — — 45µF/370V
265/1/60 0.665 1.539 — — — 40µF/370V
208–230/3/60 — — 1.117 —
460/3/60 — — 4.404 —
CL048
208-230/1/60 0.518 1.603 — — — 45µF/370V
208–230/3/60 — — 0.796 0.975 0.796 —
460/3/60 — — 4.404 —
575/3/60 — — 5.613 —
CL060
208–230/1/60 0.356 0.727 — 70µF/370V
208–230/3/60 — — 0.629 0.772 0.629 —
460/3/60 — — 3.44 —
575/3/60 — — 4.91 3.75 4.91 —
CL070
208–230/1/60 0.336 0.921 — — — 80µF/370V
208–230/3/60 — — 0.542 —
460/3/60 — — 2.161 —
575/3/60 — — 4.91 3.75 4.91 —
