Bosch CL Series User Manual

Dimensional Drawings
22 Dimensional Drawings
22.1 Vertical (VT) Unit Dimensions
Table 23 Vertical (VT) Unit Dimensions
Model CL007 CL009 CL012 CL015 CL018 CL024 CL030 CL036 CL042 CL048 CL060 CL070
Condensate Drain
Connection
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT
Recommended
Replacement Nominal
Filter Size
12" x 16" 12" x 16" 12" x 16" 17" x 19" 17" x 19" 18" x 22" 18" x 22" 19" x 27" 24" x 30" 24" x 30" 24" x 30"
20" x 27"
(2 Filters)
Condenser Water
Connections
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 1" FPT 1" FPT 1" FPT
A
Width
19" 19" 19" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 24" 24" 24"
B
Depth
19" 19" 19" 21.5" 21.5" 21.5" 21.5" 21.5" 26" 26" 26" 33"
C
Height
23" 23" 23" 33" 33" 39" 39" 39" 44" 44" 44" 58"
D
Discharge Depth
4" 4" 4" 9.75" 9.75" 9.75" 9.75" 11.5" 11.25" 11.25" 12.5" 12.5"
E
Discharge Width
6.5" 6.5" 6.5" 9" 9" 9" 9" 10.5" 10.5" 10.5" 11.75" 11.75"
F
Cabinet Edge to
Discharge
(Left-Hand
Return)
6.5" 6.5" 6.5" 4.25" 4.25" 4.25" 4.25" 2.25" 5.75" 5" 4.25" 9"
Cabinet Edge to
Discharge
(Right-Hand
Return)
2.64” 2.64” 2.64” 4.25” 4.25” 4.25” 4.25” 2.25” 5.75” 5” 4.25” 9”
G
Cabinet Edge to
Discharge
(Left-Hand
Return)
5.5" 5.5" 5.5" 6.25" 6.25" 6.25" 6.25" 6.5" 5.5" 6.75" 6.25" 6.25"
H
Water Inlet
3.5" 3.5" 3.5" 3" 3" 3.25" 3.25" 3.25" 3.25" 3" 3.25" 3"
J
Water Outlet
8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8" 8.5"
K
Condensate
Drain
6" 6" 6" 6" 6" 5.75" 5.75" 5.75" 5.75" 5.75" 5.75" 5.75"
M
R/A Duct Width
14.75" 14.75" 14.75" 17.5" 17.5" 18" 18" 18.25" 24" 24" 24" 24.25"
N
R/A Duct Flange
Height
10" 10" 10" 15.25" 15.25" 20" 20" 25" 28.25" 28.25" 28.25" 38.25"
P
Filter Rack
Height
12" 12" 12" 17.25" 17.25" 22.25" 22.25" 27" 30.75" 30" 30" 32"
Q
Cabinet Edge to
Discharge
(Right-Hand
Return)
5.5” 5.5” 5.5” 6.25" 6.25" 6.25" 6.25" 6.5" 5.5" 6.75" 6" 6"
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Overall u
nit dimensions do not include filter rack or duct
flanges.
88 |
CL Series Heat Pumps — 8733838716 (2024/05)
