20.4 Corner Weights (Horizontal Cabinets Only)
Table 21 Corner Weights (HZ)
Model
Left-Hand Evaporator Right-Hand Evaporator
Total
Left Front*
Right
Front*
Left Back Right Back Left Front*
Right
Front*
Left Back Right Back
CL007 HZ
lbs. 98.0 30.8 21.0 20.0 26.2 21.0 30.8 26.2 20.0
kg. 44.5 14.0 9.5 9.1 11.9 9.5 14.0 11.9 9.1
CL009 HZ
lbs. 106.0 32.8 23.0 22.0 28.2 23.0 32.8 28.2 22.0
kg. 48.1 14.9 10.4 10.0 12.8 10.4 14.9 12.8 10.0
CL012 HZ
lbs. 114.0 34.8 25.0 24.0 30.2 25.0 34.8 30.2 24.0
kg. 51.7 15.8 11.3 10.9 13.7 11.3 15.8 13.7 10.9
CL015 HZ
lbs. 146.8 40.2 38.6 31.4 36.6 38.6 40.2 36.6 31.4
kg. 66.6 18.2 17.5 14.2 16.6 17.5 18.2 16.6 14.2
CL018 HZ
lbs. 154.8 42.2 40.6 33.4 38.6 40.6 42.2 38.6 33.4
kg. 70.2 19.1 18.4 15.1 17.5 18.4 19.1 17.5 15.1
CL024 HZ
lbs. 183.2 45.8 58.2 42.2 37.0 58.2 45.8 37.0 42.2
kg. 83.1 20.8 26.4 19.1 16.8 26.4 20.8 16.8 19.1
CL030 HZ
lbs. 187.4 58.2 50.2 36.8 42.2 50.2 58.2 42.2 36.8
kg. 85.0 26.4 22.8 16.7 19.1 22.8 26.4 19.1 16.7
CL036 HZ
lbs. 205.2 61.6 46.6 40.6 56.4 46.6 61.6 56.4 40.6
kg. 93.1 27.9 21.1 18.4 25.6 21.1 27.9 25.6 18.4
CL042 HZ
lbs. 213.2 63.6 48.6 42.6 58.4 48.6 63.6 58.4 42.6
kg. 96.7 28.8 22.0 19.3 26.5 22.0 28.8 26.5 19.3
CL048 HZ
lbs. 266.6 77.0 74.4 52.6 62.6 74.4 77.0 62.6 52.6
kg. 120.9 34.9 33.7 23.9 28.4 33.7 34.9 28.4 23.9
CL060 HZ
lbs. 285.2 77.2 82.2 73.4 52.4 82.2 77.2 52.4 73.4
kg. 129.4 35.0 37.3 33.3 23.8 37.3 35.0 23.8 33.3
CL070 HZ
lbs. 296.2 85.0 90.6 60.2 60.4 90.6 85.0 60.4 60.2
kg. 134.4 38.6 41.1 27.3 27.4 41.1 38.6 27.4 27.3
*The front is the control box end of the unit.
