Dimensional Drawings
22.4 Horizontal (HZ) Cabinet Options Dimensions
Table 26 Horizontal (HZ) Cabinet Options Dimensions
Model
Disconnect Switch DDC Economizer Filter Racks
AA BB CC DD EE JJ FF GG HH
Disconnect Switch
Width
Disconnect Switch
Depth
DDC Panel Width DDC Panel Height Economizer Economizer Pipe 1" Filter Rack 2" Filter Rack 4" Filter Rack
CL007 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL009 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL012 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL015 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL018 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL024 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL030 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL036 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL042 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL048 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL060 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
CL070 2" 2" 9" 3" 4” 4.25" 1.25" 3" 4.75"
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Filter rack dim
ensions does not include 1" duct flange.
• 2" filter racks can accept either a 1" or 2" filter
• 4" filter racks can accept either a 2" or 4" filter
