1 689 989 464 2020-04-01| Robert Bosch GmbH
| 16 | DCU 220 | Symbols used
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices - Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the con-
sequences of the hazard as well as preventive action.
Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of
failure to observe action and information
given.
¶ Hazard prevention action and information.
The key word indicates the likelihood of occurrence
and the severity of the hazard in the event of non-
observance:
Key word Probability of
occurrence
Severity of danger if inst-
ructions not observed
DANGER Immediate impen-
ding danger
Death or severe injury
WARNING Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property dama-
ge.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several
steps.
e
One-step
operation
Instruction consisting of one step.
Intermediate
result
An instruction produces a visible in-
termediate result.
"
Final result There is a visible final result on com-
pletion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensu-
re they remain legible.
2. User information
2.1 Important notes
Important information on copyright, liability and war-
ranty provisions, as well as on equipment users and
company obligations, can be found in the separate
manual "Important notes on and safety instructions for
Bosch Test Equipment". These instructions must be
carefully studied prior to start-up, connection and ope-
ration of the DCU 220 and must always be heeded.
2.2 Safety instructions
All the pertinent safety instructions can be found in
the separate manual "Important notes on and safety
instructions for Bosch Test Equipment". These inst-
ructions must be carefully studied prior to start-up,
connection and operation of the DCU 220 and must
always be heeded.
2.3 RED (Radio Equipment Directive)
Robert Bosch GmbH hereby declares that the radio
equipment type DCU 220 conforms to the European
Directive 2014/53/EU. The complete text of the EU de-
claration of conformity is available from the following
web address: http://www.downloads.bosch-automotive.com
i In non-European countries, the corresponding
national regulations on the operation of wireless
devices in the 2.4GHz and 5GHz frequency band
must be heeded (e.g. WLAN or Bluetooth).
Druckdatum/ print date: 17.12.2010
Weitergabe sowie Vervielfältigung der Zeich-
nungen sind nicht gestattet und müssen
streng vertraulich behandelt werden. Alle
Rechte sind bei ads-tec GmbH nach DIN 34.
strictly confidential according to DIN 34.
File:Airbag Lenkrad + TT13 Doku 130
( )
Rz 10
CAUTION – risk of injury due to triggering
of the airbag with an engaged DCU 220!
Injuries due to unintentional triggering of the
airbag when attaching (e.g. engaging) the
DCU 220 to the steering wheel.
¶ Do not secure the DCU 220 to the stee-
ring wheel.
en
